Product Description
111
Product Description
Product Description
|
COMP |
ELITE |
FACTORY |
RS |
|
|---|---|---|---|---|
| FRAME | Nukeproof Megawatt 297 Alloy, 170mm travel, custom triple butted hydro-formed tube set, internal battery, Internal cable routing, Enduro Bearings, Boost 148mm rear axle spacing, 3D contoured rubber frame protection, Shimano STEPS compatible. | Nukeproof Megawatt 297 Alloy, 170mm travel, custom triple butted hydro-formed tube set, internal battery, Internal cable routing, Enduro Bearings, Boost 148mm rear axle spacing, 3D contoured rubber frame protection, Shimano STEPS compatible. | Nukeproof Megawatt 297 Alloy, 170mm travel, custom triple butted hydro-formed tube set, internal battery, Internal cable routing, Enduro Bearings, Boost 148mm rear axle spacing, 3D contoured rubber frame protection, Shimano STEPS compatible. | Nukeproof Megawatt 297 Alloy, 170mm travel, custom triple butted hydro-formed tube set, internal battery, Internal cable routing, Enduro Bearings, Boost 148mm rear axle spacing, 3D contoured rubber frame protection, Shimano STEPS compatible. |
| FORK | RockShox Domain, 29”, Motion Control RC damper, 170mm, 44mm offset, BOOST, Debonair, 1.8 Tapered Steerer, Gloss Black | Fox 38 Float, 29”, Performance Elite Series, Grip 2 Damper, 170mm, 44mm Offset, BOOST, 1.5T Steerer, 68mm Crown, Black | Fox 38 Float, 29”, Factory Series, Kashima, Grip 2 Damper, 170mm, 44mm Offset, BOOST, 1.5T Steerer, 68mm Crown, Black | RockShox Zeb Ultimate Charger 3 RC2 170mm, 44mm Offset, BOOST, Debonair, Grey |
| SHOCK | RockShox Super Deluxe Select R, Custom S/M - 0L2 LNL1 SB C1, L/XL/XXL - 0L2 LNL SB C1 tune, 230x62.5mm, bearing end, 2 bottomless tokens fitted. | Fox Float X2, Performance Series, EVOL, 2 Position lever, Custom 0.3 Spacer x2, CL, RM, Rezi CM tune, 230x62.5mm, Bearing End | Fox Float X2, Factory Series, Kashima, EVOL, 2 Position lever, Custom 0.3 Spacer x2, CL, RM tune, 230x62.5mm, Bearing End | RockShox Super Deluxe Ultimate RCT, Custom, S/M - 0L2 LNL1 32SB C1, L/XL/XXL - 0L2 LNL 32SB C1 tune, 230x62.5mm, Bearing End, 2 bottomless tokens fitted |
| WHEELSET | Front Wheel: Sun-Ringle Duroc SD37 Comp 29"", 15x110mm // Rear Wheel: Sun-Ringle Duroc SD37 Comp 27.5"", Shimano Microspline Driver, 148x12mm | Front Wheel: Nukeproof Horizon V2, 29", 6 Bolt, 110x15mm // Rear Wheel Nukeproof Horizon V2, 27.5", 6 Bolt, XD Driver, 148x12mm | Front wheel: DT Swiss H1700 SPLINE 30, 29", 6 Bolt, 110x15mm // Rear wheel: DT Swiss H1700 SPLINE 30, 27.5", 6 Bolt, XD Driver, 148x12mm | Front Wheel: Nukeproof Horizon V2, 29", 6 Bolt, 110x15mm // Rear Wheel: Nukeproof Horizon V2, 27.5", 6 Bolt, XD Driver, 148x12mm |
| DRIVE SYSTEM | Shimano STEPS EP801, 250W, 85Nm | Shimano STEPS EP801, 250W, 85Nm | Shimano STEPS EP801, 250W, 85Nm | Shimano STEPS EP801, 250W, 85Nm |
| CRANKS | e-Thirteen EP8, 165mm, 34t, BOOST | e-Thirteen EP8, 165mm, 34t, BOOST | e-Thirteen EP8, 165mm, 34t, BOOST | e-Thirteen EP8, 165mm, 34t, BOOST |
| DISPLAY | Shimano EM800 with Shimano EM800-L Assist Switch | Shimano EM800 with Shimano EM800-L Assist Switch | Shimano EM800 with Shimano EM800-L Assist Switch | Shimano EM800 with Shimano EM800-L Assist Switch |
| BATTERY / CHARGER | Shimano E8035, 504Wh | Shimano E8036, 630Wh | Shimano E8036, 630Wh | Shimano E8036, 630Wh |
| SHIFTER | Microshift Advent-X, SL-M9605-R, 10-speed | SRAM AXS POD Ultimate, 12-speed Eagle, T-Type | SRAM AXS POD Ultimate, 12-speed Eagle, T-Type | SRAM AXS POD Ultimate, 12-speed Eagle, T-Type |
| REAR DERAILLEUR | Microshift Advent-X, RD-M6205, 10-speed | SRAM GX AXS T-Type, 12-speed Eagle | SRAM XO AXS T-Type, 12-speed Eagle | SRAM XX AXS T-Type, 12-speed, Eagle |
| CHAIN | KMC, 10-speed, with Quick Link | SRAM GX T-Type, 12-speed Eagle, Flattop, PowerLock | SRAM GX T-Type, 12-speed Eagle, Flattop, PowerLock | SRAM XO T-Type, 12-speed Eagle, Flattop, PowerLock |
| CASSETTE | Microshift Advent-X, CS-G104, 10-speed, 11-48T | SRAM GX CS1275 T-Type, 12-speed, 10-52T | SRAM GX CS1275 T-Type, 12-speed, 10-52T | SRAM XO T-Type, 12-speed, Eagle, CS XG1295, 10-52T |
| CHAIN GUIDE | Nukeproof Shimano STEPS Direct Mount | Shimano EM800 drive unit mount | Nukeproof Shimano STEPS Direct Mount | Nukeproof Shimano STEPS Direct Mount |
| BRAKES | SRAM DB8, 4-piston | SRAM DB8, 4-piston | Hayes Dominion A4, 4-piston brake, metallic pads | SRAM Code RSC, Sintered pads |
| ROTORS | SRAM Centerline 220mm Front / 200mm Rear | SRAM Centerline 220mm Front / 200mm Rear | Hayes 220mm Front / 203mm Rear | SRAM HS2 220mm Front / 200mm Rear |
| TIRES | Front: Maxxis Assegai 29”x2.5 WT 3C MaxxGrip/DD/TR, Rear: Maxxis Assegai 27.5”x2.5 WT 3C MaxxGrip/DD/TR | Front: Maxxis Assegai 29”x2.5 WT 3C MaxxGrip/DD/TR, Rear: Maxxis Assegai 27.5”x2.5 WT 3C MaxxGrip/DD/TR | Front: Maxxis Assegai 29”x2.5 WT 3C MaxxGrip/DD/TR, Rear: Maxxis Assegai 27.5”x2.5 WT 3C MaxxGrip/DD/TR | Front: Michelin DH22 TLR 29”x2.4, Rear: Michelin DH22 TLR 27.5”x2.4 |
| HANDLEBARS | Nukeproof Neutron V2 31.8mm, S/M: 12mm Rise Width - 780mm, L/XL/XXL: 25mm Rise Width - 800mm | Nukeproof Horizon V2 31.8mm, S/M: 12mm Rise Width - 780mm, L/XL/XXL: 25mm Rise Width - 800mm | Nukeproof Horizon V2 31.8mm, S/M: 12mm Rise Width - 780mm, L/XL/XXL: 25mm Rise Width - 800mm | Nukeproof Horizon Carbon V2, 31.8, S/M: 12mm Rise Width - 780mm, L/XL/XXL: 25mm Rise Width - 800mm |
| STEM | Nukeproof Neutron AM, 45mm, black | Nukeproof Horizon, 45mm, black | Nukeproof Horizon, 45mm, black | Nukeproof Horizon, 45mm, black |
| SADDLE | Nukeproof, black | Nukeproof, black | Nukeproof, black | Nukeproof, black |
| SEATPOST | Brand-X Ascend internal, 31.6mm, S:125mm drop; M:150mm drop; L: 170mm drop; XL/XXL: 200mm drop | Brand X Ascend internal with Brand-X Remote lever, S:125mm drop; M:150mm drop; L:170mm drop; XL/XXL:200mm drop | BikeYoke Divine Stealth with Triggy remote lever, S:125mm drop; M:160mm drop; XL/XXL:185mm drop | BikeYoke Revive with Triggy 1x Remote, 31.6mm; S:125mm drop; M:160mm drop; L:185mm drop; XL/XXL:213mm drop |
| HEADSET | Nukeproof Neutron E-Bike Block Set, sealed bearings, ZS56/28.6 – ZS66/46 | Nukeproof Neutron E-Bike Block Set, sealed bearings, ZS56/28.6 – ZS66/46 | Nukeproof Neutron E-Bike Block Set, sealed bearings, ZS56/28.6 – ZS66/46 | Nukeproof Neutron E-Bike Block Set, sealed bearings, ZS56/28.6 – ZS66/46 |
| GRIPS | Nukeproof Sam Hill Signature | Nukeproof Sam Hill Signature | Nukeproof Sam Hill Signature | Nukeproof Sam Hill Signature |
| WEIGHT: (SIZE MEDIUM) | NA | NA | NA | NA |
